3.2. Power Supply
3.2.1. AC Input Specifications
AC Input Voltage and Frequency
Ranges
Universal Auto-Frequency Ranging Input:
100 - 120 V~ : 50/60/400 Hz
220 - 240 V~ : 50/60 Hz
Maximum Input Power
CC103: 400W
CC105: 600W
CC108 low power: 600W
CC108 and CC108-600: 900W
CC108-800: 1000W for 100-120 V
1200W for 220-240 V
Power Factor Correction Meets EN61000-3-2. Power Factor 0.95 minimum
Efficiency 75% typical @ full load
Holdover Storage
20msec minimum @ full load.
Independent of AC input voltage.
AC Input Fuse
Located within the fuse-holder on the rear panel.
All Fuses are Slow-Blow 5x20mm
CC103: T 4A H 250V
CC105: T 6.3A H 250V
CC108 low power: T 6.3A H 250V
CC108 and CC108-600: T 10A H 250V
CC108-800: T 10A H 250 V for 100-120 V
T 6.3A H 250 V for 220-240 V
AC Input Inlet IEC320 C14
Main Power Switches 2 switches in series: on the front and rear panels
Internal Fuse (F401)
Type ABC manufactured by Bussman or
type 314 manufactured by Littelfuse.
CC103, CC105, CC108 low power: 10A, 250V
CC108 and CC108-600: 15A, 250V
CC108-800: 10A, 250V for each supply
Power Supply Cooling
Internal DC Fan. The airflow direction is from the right
to the left side of the crate.
User Manual: Agilent Acqiris 3-, 5-, and 8-slot cPCI Crates Page 13 of 28
