1. OUT OF THE BOX
1.1. Message to the User
Congratulations on having purchased an Agilent Technologies Acqiris product. CC10X, crates use the highest
quality components and high output power supplies in order to maximize system performance and reliability. These
universally applicable CompactPCI crates are carefully designed to yield high performance test systems for bench,
lab and manufacturing test applications.
1.2. Before Using Your Crate
This manual covers the entire family of Acqiris 6U CompactPCI crates. These crates differ in number of slots and in
total usable power.
U1091AC30 - Model CC103 CompactPCI crate with 3 slots.
U1091AC50 - Model CC105 CompactPCI crate with 5 slots.
U1091AC80 - Model CC108 low power, CC108, and CC108-600 CompactPCI crates with 8 slots.
U1091AC83 - Model CC108-800 CompactPCI crates with 8 slots.
The terminology CC10X is used throughout this manual when descriptions or specifications relate to the entire
family.
This User Manual describes the features of the CC10X crate and contains information for your safety, about
configuring the crate, installing the modules, and operating the system.
1.3. Organization of This Manual
This manual is organized as follows :
Chapter 1 OUT OF THE BOX, gives information you must know prior to using CC10X crates, lists the
cont
ents of the box, lists optional equipment you can order from us, and describes the warranty and
repair return procedure.
Chapter 2 INSTALLATION, describes how to prepare and operate your CC10X crate.
Ch
apter 3 SPECIFICATIONS, gives complete technical specifications
of your CC10X crate.
Chapter 4 APPENDICES, gives specifications and assembly instructions supplied with the optional
equi
pments.
1.4. Conventions Used in This Manual
The following conventions are used in this manual :
Th
is icon to the left of text warns that an important point must be observed.
WARNING Denotes a warning, which advises you of precautions to take to avoid being electrically shocked.
CAUTION Denotes a caution, which advises you of precautions to take to avoid electrical, mechanical, or
operational damages.
NOTE Denotes a note, which alerts you to important information.
Italic Italic text denotes a warning, caution, or note.
Bold Italic Bold italicized text is used to emphasize an important point in the text or a note
