Agilent Technologies ACQIRIS CC103 User Manual

3.2.2. DC Outputs Specifications
Maximum Usable Power
CC103: 270W
CC105: 400W
CC108 low power: 400W
CC108 and CC108-600: 600W
CC108-800: 600W for 100-120 V
800W for 220-240 V
Output Voltages
+3.3V: +3.3 −0.1V, +0.15 V
+5V: +5.1 ±0.1V
+12V: +12.15 ±0.15V
−12V: −12.15 ±0.15V
Maximum Output Currents
CC103, CC105, CC108 low power and CC108:
+3.3V: 60A (198W)
+5V: 35A (175W)
+12V: 17A (204W)
−12V: 17A (204W)
CC108-600:
+3.3V: 60A (198W)
+5V: 60A (300W)
+12V: 9A (108W)
−12V: 4A (48W)
CC108-800:
+3.3V: 120A(396W) with P(+3.3)+P(+12)< 400 W
+5V: 80A (400W) with P(-12)+P(5)< 400 W
+12V: 17A (204W)
−12V: 17A (204W)
RMS Ripple 0.1% or 10mV whichever is greater. 20MHz bandwidth
Peak to Peak Noise 1% or 50mV whichever is greater. 20MHz bandwidth
Dynamic Response <2% or 100mV @ 25% load step
Recovery Time To within 1% in <0.3msec
Over-Current Protection
All outputs are protected from short circuit and
overload.
Automatic recovery.
Over-Voltage Protection
3.3V and 5V: 122-134%
+12V and –12V: 110-120%.
Turn OFF the crate to reset the Over Voltage Protection.
Thermal Protection
All outputs are disabled when the power supply internal
temperature exceeds safe operating range.
Warning signal (DEG#) >5msec before shutdown.
Automatic recovery.
User Manual: Agilent Acqiris 3-, 5-, and 8-slot cPCI Crates Page 14 of 28
