3.6. Mechanical
3.6.1. Mechanical Specifications
Overall Dimensions
Width: 342mm (13.47 in.)
Depth: 346mm (13.63 in.)
Height: including the feet
CC103: 106mm (4.17 in.)
CC105: 146mm (5.75 in.)
CC108: 212mm (8.35 in.)
Overall Dimensions with Rack-
mount Adapter
Width with adapter: 482.6mm (19 in.)
Depth with handles: 385.0mm (15.16 in.)
Height with adapter:
CC103 with XC103: 3U, 132.5mm (5.22 in.)
CC105 with XC105: 4U, 177.0mm (6.97 in.)
CC108 with XC108: 5U, 221.4mm (8.72 in.)
Weight
CC103: 6.8 kg (15.0 lb.)
CC105: 7.3 kg (16.1 lb.)
CC108: 8.5 kg (18.8 lb.)
CC108-800: 11.3 kg (24.8 lb.)
Materials
Enclosure: Steel sheet
Aluminum extrusion
Covers: Polystyrene (UL 94V0 rated)
Card Guides: Molded plastic (UL 94V0 rated)
Finish
Enclosure: Zinc plated and exterior painted
Alodine (conductive)
User Manual: Agilent Acqiris 3-, 5-, and 8-slot cPCI Crates Page 19 of 28
