3.6.2. Dimensions
All dimensions in mm
Slots A B C D
CC103
3 106 68.3 42 13.15
CC105
5 146 108.9 84 12.45
CC108
8 212 174.9 150 12.45
NOTE : The front and rear mounting holes M4 are symmetrical.
User Manual: Agilent Acqiris 3-, 5-, and 8-slot cPCI Crates Page 20 of 28
