19
Changing the Bravo head
Bravo Platform Quick Guide
b Place your right hand under the flat area just to the left of the barrel or syringe
array to support the weight of the head.
5 While supporting the head with your hands, slide the head to the left and out of the
Bravo head mount.
Support the head securely without touching the barrels, probes, or pins. Dropping the
head or bumping the barrels, probes, or pins will damage the head.
6 Carefully place the head into the storage stand, as follows:
• Disposable-tip heads. Rest the bottom of the stand on a clean, dry surface.
Slide the head into the stand, with the barrels facing down, as the following
figure shows.
Figure
Series III disposable-tip head and storage stand
• Pin Tools. Rest the top of the head on a clean, dry surface with the pins facing
up. Slide the stand onto the head.
Store the head top-side up and resting in the head stand.
