Scheduled Maintenance Cards
100/140 Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L)
Unscheduled Maintenance Card No.
103
Pump type: DS102 1Ph, DS202 1Ph, DS302 1Ph, DS402 1Ph, DS402 3Ph, DS602 1Ph, DS602 3Ph
Frequency: WHEN DAMAGED Time: 30 min Machine status: S R
Type of action: DISASSEMBLY
Item: SIGHT GLASS
Figure 18
Materials required: Equipment required:
OR gaskets
(for pumps DS102 1Ph, DS202 1Ph and DS302
1Ph Gaskets kit p/n 949-9370)
(for pumps DS402 1Ph, DS402 3Ph, DS602 1Ph
and DS602 3Ph Gaskets kit p/n 949-9371)
Sight glass
Mechanical tools
ACTION AREA
