5
Technical Description
Electrical motors
68/140 Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L)
NOTE
If fuses are installed on the power line, they must be in accordance with the
table below.
If you start a pump at low temperature, the current absorbed by the
motors will be for several seconds higher than the nominal one, for
this reason the fuse on the line must be of the slow-blow type.
Tab. 6
PUMP NOMINAL
VOLTAGE
[V]
HZ RPM KW START UP
CURRENT [A]
FULL LOAD
CURRENT
[A]
MAXIMUM FUSE
RATING [A]
DS 102
DS 202
DS 302
100 50 1450 0.45 44 8.8 10
100 to 120 60 1730 0.55 42 8.8 10
200 to 240 50 1450 0.45 27 5.4 8
200 to 230 60 1730 0.55 24 4.4 6
DS 402
DS 602
100 50 1450 0.75 75 11.8 16
100 to 120 60 1730 0.90 82 12.8 16
200 to 240 50 1450 0.75 43 6.2 8
200 to 230 60 1730 0.90 39 6.4 8
Single-Phase Universal Motors Voltage Setting
CAUTION!
Before connecting to the mains, check that your electrical mains voltage
corresponds to the motor voltage setting.
