5
Technical Description
Three Phase Universal Motors
70/140 Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L)
Figure 8 Motor Electrical box
Three Phase Universal Motors
They are world wide motors in accordance with major international
standards (UL, CSA, CE). On the table below are shown the technical
specifications of the different motors.
CAUTION!
Before starting the pump, give a short activation to the power switch, in order to
check that the motor turns in the direction indicated by the arrow on the motor
body. Should it rotate in the opposite direction, invert the connection of any two
phases on the motor terminals.
Volta
e Selector
Orange label
(100 to 120 V)
On/off switch
IEC 320 main socket
