Instructions for Use
Installation
4
Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L) 43/140
Installation
Do not install or use the pump in an environment exposed to
atmospheric agents (rain, snow, ice), dust, aggressive gases, or in
explosive environments or those with a high fire risk. During
operation, the following environmental conditions must be respected:
temperature: from +12 °C to +40 °C
relative humidity: 0 – 95 % (non-condensing)
WARNING!
Protect against short circuits and overload by installing on Agilent Device
electrical main line an automatic circuit breaker of proper capacity (see
table here below):
Tab. 1
P/N 110 Vac 220 Vac 380 Vac
949-9315 10 A 6 A
949-9320 10 A 6 A
949-9325 10 A 6 A
949-9330 16 A 7.5 A
949-9331 6 A 6 A
949-9335 16 A 7.5 A
949-9336 6 A 4 A
CAUTION!
Before starting the pump, fill up with lubricating oil as the pump is delivered
empty.
