Agilent Technologies DS102 1Ph - Page 110

5
Technical Description
Scheduled Maintenance Cards
110/140 Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L)
WARNING!
If you have to perform maintenance on the pump after a considerable time in
operation, leave it to cool as temperature of the outer surface may be in
excess of 60 °C.
Figure 26
