Technical Description
Scheduled Maintenance Cards
5
Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L) 115/140
Unscheduled Maintenance Card No.
108
Pump type: DS102 1Ph, DS202 1Ph, DS302 1Ph, DS402 1Ph, DS402 3Ph, DS602 1Ph, DS602 3Ph
Frequency: WHEN DAMAGED Time: 1 hour Machine status: S R
Type of action: DISASSEMBLY
Item: ANTI-SUCKBACK DEVICE
Figure 29
Materials required: Equipment required:
Gasket kit
Mechanical tools
WARNING!
Machine safety: disconnect all power lines. Hang the card “MACHINE
UNDERGOING MAINTENANCE - DO NOT POWER ON” from the main breaker
switch. When finished, remove the safety warning.
ACTION AREA
