Agilent Technologies DS102 1Ph User Manual

Technical Description
Scheduled Maintenance Cards
5
Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L) 127/140
Figure 37
1. Drain off all the oil from the pump.
NOTE
For a description of how to drain off the oil, see the Unscheduled Maintenance
Card No. 102.
2. Detach the entire functional block from the pump support.
NOTE
For a description of how to separate the functional block from the support, see
the Unscheduled Maintenance Card No. 109.
3. Disassemble the discharge valves.

Agilent Technologies DS102 1Ph Specifications

General

Brand	Agilent Technologies
Model	DS102 1Ph
Category	Water Pump
Language	English
