Agilent Technologies DS102 1Ph User Manual

Technical Description
Anti-Suckback Device
5
Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L) 57/140
N° DESCRIPTION DS 102 DS202 DS302 DS402 DS602
26 Inlet screen SR03700237 SR03700237 SR03700237 SR03700237 SR03700237
27 OR gasket (4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
28 Suction flange
29
Anti-suckback
shutter
(4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
30 Piston
31 OR gasket (4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
32 Casing gasket (4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
33 Inner plate SR03700260 SR03700260 SR03700260 SR03700362 SR03700362
34 Pump support
35
Anti-wear
bushing
SR03700370 SR03700370
36 OR gasket (4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
37 Kei motor side
SR899998010
1
SR899998010
1
SR899998010
1
SR899998030
1
SR899998030
1
38
First stage
vane
(1) (2) (2) (3) (3)
39
First stage
rotor
SR03700273 SR03700319 SR03700319 SR03700371 SR03700371
40 Spring (4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
41 Tongue
SR899998000
1
SR899998000
1
SR899998000
1
SR899998040
1
SR899998040
1
42
Second stage
vane
(1) (2) (2) (3) (3)
43
Second stage
rotor
SR03700269 SR03700269 SR03700269 SR03700367 SR03700367
44 Tie-rod SR03700209 SR03700308 SR03700308 SR03700335 SR03700335
45 OR gasket (4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
46 Bracket
47 Screw
49
Valve cover
plate
50 Valve spring (4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
