Technical Description
Anti-Suckback Device
5
Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L) 59/140
N° DESCRIPTION DS 102 DS202 DS302 DS402 DS602
83 Spring
84 Filter
85 Flange
86 Sight glass 03.701326 03.701326 03.701326 03.701326 03.701326
87 OR gasket (4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
99 Special screw
100 Piston
101 Arm
102 Spring (1) (2) (2) (3) (3)
103 OR gasket (4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
104 OR gasket (4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
105 Sleeve
106 Spring (1) (2) (2) (3) (3)
107 Ring (4) - (1) (4) - (2) (4) - (2) (5) - (3) (5) - (3)
108 Arm
109 Insert
110
Special
washer
111 Screw
NOTES
Tab. 3
1 Part of DS 102 Major Maintenance Kit (P/N 9499380)
2 Part of DS 202-302 Major Maintenance Kit (P/N9499381)
3 Part of DS 402-602 Major Maintenance Kit (P/N 9499382)
4 Part of DS 102-202-302 Minor Maintenance Kit (P/N 9499370)
5 Part of DS 402-602 Minor Maintenance Kit (P/N 9499371)
