Agilent Technologies DS102 1Ph User Manual

Technical Description
Technical Data
5
Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L) 61/140
TECHNICAL DATA Hz UNITS DS102 DS202 DS302 DS402 DS602
OIL
TEMPERATURE
°C 50 50 52 70 72
(pump
operating)**
°F 122 122 126 158 162
Installation
category
II
Pollution degree 2
OPERATING
TEMPERATURE
RANGE
°C 12 - 40 12 - 40 12 - 40 12 - 40 12 - 40
WEIGHT Kg 22 24 24 36 36
lb 48 53 53 79 79
INLET FLANGE DN 25KF 25KF 25KF 25KF 25KF
EXHAUST FLANGE DN 25KF 25KF 25KF 25KF 25KF
Dimensions (cf.
also next table):
- length, 1ph mm 454 491 491 530 530
- width mm 134 134 134 164 164
- height mm 212 212 212 242 242
Input single phase versions ***
Nominal voltages: 50 V 100
200-240
100
200-240
100
200-240
100
200-240
100
200-240
60 V 100-120
200-230
100-120
200-230
100-120
200-230
100-120
200-230
100-120
200-230
Maximum
currents:
50 A 8,8
5,4
8,8
5,4
8,8
5,4
11,8
6,2
11,8
6,2
60 A 8,8
4,4
8,8
4,4
8,8
4,4
12,8
6,4
1,8
6,4
* According to PNEUROP 6602
** At ultimate total pressure, 20 °C (68 °F) room temperature
*** For more details about the electrical motors see pages from 17 to 20

Agilent Technologies DS102 1Ph Specifications

General

Brand	Agilent Technologies
Model	DS102 1Ph
Category	Water Pump
Language	English
