Scheduled Maintenance Cards
94/140 Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L)
Tab. 11
KIT Pump Type ORDER
CODE
DS102 1Ph DS202 1Ph DS302 1Ph
DS402 1Ph
DS402 3Ph
DS602 1Ph
DS602 3Ph
GASKETS KIT X X X 949-9370
GASKETS KIT
X X 949-9371
MAINTENANCE KIT
X 949-9380
MAINTENANCE KIT
X X 949-9381
MAINTENANCE KIT X X 949-9382
GASKETS KIT X X X 949-9370
5. Before reassembling the pump, all parts must be cleaned
thoroughly with a soap and water solution and rinsed with
demineralized water.
CAUTION!
Particular care must be taken in cleaning the lubrication ducts and oil passage
nozzles, which must always be kept free of impurities.
CAUTION!
Take care that the soap and water solution does not remain in the various
cavities and recesses of the pump, in the blind holes in particular.
6. Then dry the parts, by heating where possible but without using
compressed air (it generally contains polluting substances),
taking care not to exceed a temperature of 80 °C.
7. The sequence of reassembly is the inverse of the disassembly
operation. Take the same precautions:
