Technical Description
Scheduled Maintenance Cards
96/140 Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L)
Unscheduled Maintenance Card No.
102
Pump type: DS102 1Ph, DS202 1Ph, DS302 1Ph, DS402 1Ph, DS402 3Ph, DS602 1Ph, DS602 3Ph
Frequency: AS REQUIRED Time: 30 min Machine status: S R
Type of action: CHANGING OIL
Item: LUBRICANT 949-9390
Figure 16
Materials required: Equipment required:
Agilent Rotary Vane Fluid DS19
Type (1 liter) P/N 949-9390
Fixed wrench for oil exhaust.
Tank to collect oil.
Cotton (or other suitable material) rags for cleaning.
Soap and water solution for cleaning.
ACTION AREA
