Chapter 2 Quick Start
To use the power supply in constant current mode
34
5 Adjust the knob for the desired voltage limit.
1
Check that the knob is still selected for voltage control and the Lmt annunciator
blinks. Adjust the knob for the desired voltage limit.
6 Adjust the knob for the desired output current.
1
Set the knob for current control. The second digit of the ammeter will be blinking.
Adjust the knob to the desired current output.
7 Return to the meter mode.
Press the key or let the display time-out after several seconds to
return the meter mode. Notice that the Lmt annunciator turns off and the display
returns to the meter mode. In the meter mode, the display shows the actual output
voltage and current of the selected supply.
8 Verify that the power supply is in the constant current mode.
If you operate the +6V supply in the constant current (CC) mode, verify that CC and
+6V annunciators are lit. If you operate the power supply for +25V supply or -25V
supply, the +25V or -25V annunciator will turn on. If the CV annunciator is lit, choose
a higher voltage limit.
Note During actual CC operation, if a load change causes the voltage limit to be exceeded,
the power supply will automatically crossover to constant voltage mode at the preset
voltage limit and the output current will drop proportionately.
1
You can use the resolution selection keys to move the blinking digit to the right or left when
setting the voltage and current.
