Chapter 2 Quick Start
To store and recall the instrument state
36
To store and recall the instrument state
You can store up to three different operating states in non-volatile memory. This also
enables you to recall the entire instrument state with just a few key presses from the
front panel.
The memory locations are supplied from the factory for front panel operation with
the following states: display and knob selection for +6V output; *RST values of
voltage and current limits for three outputs; output disabled; and track off state. *RST
values for +6V supply are 0 V and 5 A and 0 V and 1 A for the ±25V supplies.
The following steps show you how to store and recall an operating state.
1 Set up the power supply for the desired operating state.
The storage feature "remembers" the display and knob selection state, the limit values
of voltage and current for three outputs, output on/off state, and track mode state.
2 Turn on the storage mode.
Three memory locations (numbered 1, 2, and 3) are available to store the operating
states. The operating states are stored in non-volatile memory and are remembered
when being recalled.
This message appears on the display for approximately 3 seconds.
3 Store the operating state in memory location "3".
Turn the knob to the right to specify the memory location 3.
To cancel the store operation, let the display time-out after 3 seconds or press any
other function key except the key. The power supply returns to the normal
operating mode and to the function pressed.
STORE 1
STORE 3
To Next Page
