Chapter 2 Quick Start
To rack mount the power supply
38
To rack mount the power supply
The power supply can be mounted in a standard 19-inch rack cabinet using one of
three optional kits available. A rack-mounting kit for a single instrument is available
as Option 1CM (P/N 5062-3957). Installation instructions and hardware are included
with each rack-mounting kit. Any Agilent Technologies System II instrument of the
same size can be rack-mounted beside the Agilent E3631A power supply. To rack
mount the power supply, follow these procedures.
Remove the front and rear bumpers before rack-mounting the power supply.
To remove the rear bumper, pull the bumper off from the top as there are
protrusions on the sides and bottom of the cover."
To rack mount a single instrument, order adapter kit 5063-9243.
