3-48 Chapter3
Functional Testing
Tracking Generator Level Flatness: HP E4401B and E4411B, Options 1DN
and 1DQ
7. Enter the appropriate power sensor Cal Factor for the test frequency
into the power meter as indicated on the label of the power sensor.
8. Record the power level displayed on the power meter as the Level
Flatness in Table 3-8.
9. Repeat steps 7 through 8 to measure the flatness at each center
frequency setting listed in Table 3-8. The ⇑ may be used to tune to
center frequencies above 500 MHz.
NOTE 75 Ω RF Out only: Repeat steps 5 through 7 to measure the flatness at
the frequencies above 1 MHz listed in Table 3-8.
Table 3-8 Tracking Generator Level Flatness Worksheet
Center Frequency Level Flatness (dB)
100 kHz or 1 MHz
a
a. This frequency is 100 kHz for analyz-
ers with 50 Ω tracking generators,
and 1 MHz for analyzers with 75 Ω
tracking generators.
5 MHz
40 MHz
50 MHz 0 (Ref)
80 MHz
500 MHz
1000 MHz
1500 MHz
To Next Page
