6-50 Chapter6
Front-Panel Key Reference
Meas Control
Meas Control
Accesses a menu of keys that allow you to pause or restart one of the
measurements available in the
MEASURE key menu. Meas Control also
allows you to select between continuous and single sweeps or
measurements.
Press
MEASURE and then select one of the available measurements
(
ACP, Channel Power, Occupied BW, Emission BW, or Harmonic Dist).
Once the desired measurement is selected, press
Meas Control. Meas
Control accesses the following keys:
Restart Performs the same functions as the “Restart” front-panel key.
Measure Cont
Single
Measure (Single) allows you to take one measurement sweep and display
the measurement results.
Measure (Cont) allows you to continuously run
a measurement, displaying the results after each measurement sweep.
Pause Allows you to pause a measurement. Pressing Pause will toggle
between pausing and resuming your measurement. The key label will
toggle between
Pause and Resume.
Resume Allows you to resume a measurement that had been paused. The key
label will toggle between
Pause and Resume.
NOTE The measurements described above are those available in SA mode (see
Mode key). Other measurements are available in other modes if an
optional personality is installed.
