3-28 Chapter3
Functional Testing
Frequency Response
Required Equipment
Instrument
Critical
Specifications
(for this test)
Recommended
HP/Agilent Model
Signal Sources
Synthesized Sweeper 8340A/B or 83630A
Series
Adapters
Type-N (f) to BNC (f) 1250-1474
APC 3.5 (f) to
APC 3.5 (f)
5061-5311
BNC(f) to SMA(m) 1250-1237
Type-N(m), to APC
3.5(m)
1250-1743
Cables
(2) APC 3.5mm (36in) 8120-4921
BNC(m) both ends,
(48in)
10503A
Additional Equipment for 75-ohm Input
Pad, minimum loss 11852B
Type-N (f), to
BNC (m)
1250-1534
Misc
Power Meter EPM-441A (E4418A)
Power Sensor, 75 Ω 8483A
Power Sensor, 50 Ω 8485A
Power Splitter 11667B
To Next Page
