6-24 Chapter6
Front-Panel Key Reference
Display
Title Accesses the following Title menu keys which allows you to change or
clear a title on your display. Key Access:
Display
Change Title Allows you to write a title across the top of the display.
The marker readout may interfere with the last
characters. The markers can be turned off by pressing
Marker, More 1 of 2, Marker All Off. Pressing Change Title
accesses the Alpha Editor Menus that contain available
characters and symbols.
NOTE Pressing ESC before exiting the Alpha Editor menus will retain the
previous title.
The display title will remain until either
Change Title is
pressed again, or a trace is recalled that was previously
saved with a title. A display title can also be cleared by
using the clear function. Press
Display, Title, Clear Title.
Key Access:
Display, Title
Clear Title Allows you to clear a title from the front-panel display.
Once cleared, the title cannot be retrieved. Key Access:
Display, Title
Preferences Accesses a menu of the following display functions which allow you to
turn the graticule and annotation on or off. Key Access:
Display
Graticule
On Off Turns the display graticule on and off.
Key Access:
Display, Preferences
Annotation
On Off Turns the screen annotation on or off, however, menu
key annotation will remain on the screen. The screen
annotation may not be required for prints or during
remote operation. Key Access:
Display, Preferences
