Specifications
Power Meter Specifications
1-4 Agilent E4418B/E4419B Service Guide
Accuracy
Instrumentation
Absolute: ±0.02 dB (Logarithmic) or ±0.5% (Linear). (Refer to the power
sensor linearity specification in your power sensor manual to assess
overall system accuracy.)
Relative: ±0.04 dB (Logarithmic) or ±1.0% (Linear). (Refer to the power
sensor linearity specification in your power sensor manual to assess
overall system accuracy.)
Zero Set (digital settability of zero): Power sensor dependent (refer to
Table 1-1). For Agilent E-series power sensors, this specification applies
when zeroing is performed with the sensor input disconnected from the
POWER REF.
Table 1-1: Zero Set Specifications
Power Sensor Zero Set
Agilent 8481A ±50 nW
Agilent 8481B ±50 µW
Agilent 8481D ±20 pW
Agilent 8481H ±5 µW
Agilent 8482A ±50 nW
Agilent 8482B ±50 µW
Agilent 8482H ±5 µW
Agilent 8483A ±50 nW
Agilent 8485A ±50 nW
Agilent 8485D ±20 pW
Agilent R8486A ±50 nW
Agilent R8486D ±30 pW
Agilent Q8486A ±50 nW
Agilent Q8486D ±30 pW
Agilent V8486A ±200 nW
Agilent W8486A ±200 nW
Agilent 8487A ±50 nW
Agilent 8487D ±20 pW
Agilent E4412A ±50 pW
Agilent E4413A ±50 pW
