Performance Tests
Introduction
Agilent E4418B/E4419B Service Guide 2-3
Equipment Required
Table 2-1 lists all the equipment required for the adjustments and
performance tests. If substitutions must be made, the equipment used
must meet the critical specifications.
Table 2-1: Required Equipment
Equipment
Required
Model Number Critical Specification Usage
1
1. P = Performance Tests, A = Adjustments
Digital Multimeter Agilent 3458A Range 0 to 20 V
Resolution 0.01 V
P and A
DC Calibrator Datron 4000A
or
Fluke 5720A
P
Range Calibrator
Agilent 11683A
or
Agilent 11683A
Opt H01
Option H01 is essential for
accurate verification. (See
analysis in
Appendix A). The
Standard 11683A can be used
for indication only.
P
Frequency Counter Agilent 53132A Range 10 Hz to 50 MHz
Resolution 1 Hz
P and A
Power Meter Agilent 432A Range 1 mW
Transfer Accuracy 0.2%
P and A
Thermistor Mount Agilent 478A Opt H75/H76
or
Agilent 8478B Opt H01
SWR<1.05 at 50 MHz
Accuracy ±0.2% at 50 MHz.
P and A
Power Sensor Agilent E-series power
sensor
P
30 dB Attenuator Agilent 11708A
or
Agilent 8491A Option 030
P
Power Sensor
Cable
Agilent 11730A
or
Agilent
E9288A
P and A
