Replaceable Parts
Assembly Part Numbers
Agilent E4418B/E4419B Service Guide 5-5
Power Supply Assembly Types
Before ordering an A1 Power Supply Assembly, check connector J2 and compare it to
Figure 5-1 and Figure 5-2 and select the appropriate model. The J2 connector is found
nearest the fan assembly.
Figure 5-1: 0950-2649 Power Supply Assembly
Figure 5-2: 0950-3681 Power Supply and Charger Assembly
Front Power Reference Cable Kit E4418-61811
Rear Power Reference Cable Kit E4418-61813
Reference
Designator
Description
Agilent Part
Number
