Performance Tests
Performance Test Record
2-30 Agilent E4418B/E4419B Service Guide
Performance Test Record
Model Agilent E4418B/E4419B Power Meter
Tested by ___________________________________________
Serial Number _______________________________________
Date _______________
Table 2-8: Performance Test Record
Test
Min
Result
Channel A
Actual
Result
Channel B
Actual
Result
Max
Result
Zero Test −76.40 nW +76.40 nW
Instrument Accuracy
3.1623 µW
10 µW
31.6228 µW
100 µW
316.227 µW
1 mW
3.1623 mW
10 mW
31.6228 mW
100 mW
3.0977 µW
9.904 µW
31.428 µW
99.49 µW
314.72 µW
0.9954 mW
3.1477 mW
9.954 mW
31.477 mW
99.54 mW
___________
___________
___________
___________
___________
___________
___________
___________
___________
___________
___________
___________
___________
___________
___________
___________
___________
___________
___________
___________
3.2269 µW
10.096 µW
31.819 µW
100.51µW
317.74 µW
1.0047 mW
3.1769 mW
10.046 mW
31.769 mW
100.46 mW
Power Reference
P
meas
0.999 mW ___________ ___________ 1.001 mW
Interface Test Pass/Fail ___________ ___________ Pass/Fail
Functional Test
Low Range, 30 dBm pad
Low Range, 30 dBm pad
Low Range, no pad
Upper Range, no pad
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
___________
___________
___________
___________
___________
___________
___________
___________
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
