Performance Tests
Instrument Accuracy Test
2-10 Agilent E4418B/E4419B Service Guide
Table 2-3: Instrument Accuracy Results (For Indication Only)
Note The nominal outputs for the 3 µW, 30 µW, 300 µW, 3 mW, 10 mW,
30 mW and, 100 mW settings are 3.16 µW, 31.6 µW, 316 µW,
3.156 mW, 10.03 mW, 31.78 mW, and 101.3 mW respectively.
Note It is not necessary to check instrument accuracy in dBm. The
power meter uses the same internal circuitry to measure power
and mathematically converts watts to dBm.
Range
Calibrator
Setting
Min
1
1. These performance limits are determined by the zero set specification of the power sensor
used in the measurement plus the measurement noise.
Channel A
Actual Results
Channel B
Actual Results
(Agilent E4419
B only)
Max
1
3 µW3.100 µW _______________ _______________ 3.230 µW
10 µW9.900 µW _______________ _______________ 10.10 µW
30 µW 31.40 µW _______________ _______________ 31.80 µW
100 µW 99.50 µW _______________ _______________ 100.5 µW
300 µW 314.00 µW _______________ _______________ 318.00 µW
1 mW 0.995 mW _______________ _______________ 1.005 mW
3 mW 3.141 mW _______________ _______________ 3.171 mW
10 mW 9.984 mW _______________ _______________ 10.08 mW
30 mW 31.63 mW _______________ _______________ 31.94 mW
100 mW 100.9 mW _______________ _______________ 101.8 mW
4402serv.book Page 10 Tuesday, October 14, 2003 3:18 PM
