Agilent Technologies E4445A Service Guide

Chapter 10 245
Replaceable Parts Lists and Locations
Replaceable Parts
W97, not assigned
W98, Cable, semi-rigid,
LO In to Unpreselected
Mixer from W46/3 dB pad
(Option 123)
E4446-20074 X X X
W99, Cable, semi-rigid,
Unpreselected mixer to
switch 5 (bottom switch)
Port 4 (Option 123)
E4446-20318 X X X
W100, Cable, semi-rigid,
Switch 5 port 1 from
attenuator
(Option 123, for
instruments that do not
have Option 110)
E4446-20071 X X X
W101, Cable, semi-rigid,
Switch 4 port 4 to Switch 5
port 1
(Option 123, for
combination of Option 110
with Option 123)
E4446-20081 X X X
W102, Cable, semi-rigid,
A15 Attenuator out to
Switch 4 port 1
(Option 110)
E4446-20077 X X X
W103, Cable, semi-rigid,
Preamp In from Switch 4
port 2 (Option 110)
E4446-20078 X X X
W104, Cable, semi-rigid,
Preamp out to Switch 4
port 3 (Option 110)
E4446-20083 X X X
W105, Cable, semi-rigid,
Switch 5 port 2 to W34 cable
to A10 RHYTHM/SBTX
(Option 123)
E4446-20080 X X X
W106, Wire Harness,
Option Driver P1 to Preamp
(Option 110)
E4446-60076 X X X X X X
Table 10-3 Cables
a
Description Part
Number
E4440A E4443A E4445A E4446A E4447A E4448A
