22 Chapter 1
Overview
Service Equipment You Will Need
Service Equipment You Will Need
The service kit facilitates making measurements on various assemblies
within the instrument. Refer to Table 1-3 for a list of recommended
Agilent test equipment used for making measurements. Alternative
equipment model numbers are given in case the recommended
equipment is not available.
NOTE If neither the recommended nor the alternative test equipment are
available, you may use substitute equipment that meets or exceeds the
critical specifications required to perform measurements.
Service Kit Parts List
The service kit contains extender boards that enable access to
measurement points that cannot otherwise be accessed when the
instrument is operational.
Table 1-2 Agilent Service Kit (Agilent part number E4440-60090)
Agilent Part Agilent Part Number Specifications
Extender Boards
A7 DIF Extender Board E4406-60021
A8 AIF, A9 2
nd
LO
Extender Board
E4440-60048
A10, A11, A12, A13
Extender Board
E4440-60049
A13J12 Bias Adjustment Board E4440-60041
Synthesizer Extender Board
Guides (2 ea.)
E4440-00025
Synthesizer Board Support (2 ea.) E4440-00026
Synthesizer Board Support (2 ea.) E4440-20113
Cables
20-Conductor Ribbon Cable (3 ea.) E4440-60331 Specific to preamp,
electronic attenuator,
FIFA.
10-Conductor Ribbon Cable E4440-60332 Specific to SLODA.
8-Conductor Ribbon Cable E4440-60333 Specific to YTO.
