Chapter 10 261
Replaceable Parts Lists and Locations
Hardware
Reference
Designator
Description Agilent Part
Number
W7 W7 Cable, semi-rigid (with ferrites), For standard “N” type RF
Input to A14 Attenuator
E4440-20067
W8 W8 Cable, semi-rigid (with ferrites), A14 attenuator to A15
attenuator
E4440-20068
W9 W9 Cable, semi-rigid, A15 Attenuator to A19 RYTHM E4440-20069
W15 W15 Cable, semi-rigid, A9 2nd LO, J10 to Lowband, J5 E4440-20084
W17 W17 Cable (10), coax (with ferrites), A19 RYTHM highband
output to A10 3rd Converter J1
E4440-60371
W18 W18 Cable (7), coax (with ferrites), 321.4 MHz A20 Lowband
assy to A10 3rd Converter J2
E4440-60372
W20 W20 Cable (50), coax, 50 MHz Cal signal from A10 3rd
Converter J7 to A14 Attenuator
8121-0156
W24 W24 Cable, semi-rigid, A21 SLODA to A12 Synthesizer E4440-20082
W35 W35 Cable, semi-rigid, YTO Output A18 YTO to A21 SLODA E4440-20083
W36 W36 Cable, semi-rigid, A19 RYTHM to FL1 Low Pass Filter
(except Option B7J)
E4440-20071
W37 W37 Cable, semi-rigid, FL1 Low Pass Filter to A20 Lowband
Assy. J1 (except Option 1DS)
E4440-20074
W38 W38 Cable, semi-rigid, LO signal A21 SLODA to A19 RYTHM E4440-20070
W39 W39 Cable, semi-rigid, Bandpass Filter Output, 3.9 MHz
Bandpass Filter to A20 Lowband J4
E4440-20081
W40 W40 Cable, semi-rigid, Bandpass Filter Input, A20 Lowband J3
to FL2, 3.9 MHz Bandpass
E4440-20080
W41 W41 Cable, semi-rigid, A21 SLODA to A20 Lowband Assy. E4440-20076
To Next Page
