Chapter 10 269
Replaceable Parts Lists and Locations
Hardware
Item Description Agilent Part Number
1 J1 Input Connector, 2.4 mm 5064-3970
2 A14 Input Attenuator (10 dB)/Switch) 33326-60009
3 A15 Input Attenuator (60 dB) 33325-60009
4 L-bracket, RF Main E4446-00003
5 A18 YTO, 2.9 to 7 GHz (Yig Tuned Oscillator) E4440-60023
6 A19 SBTX/RYTHM Assembly, 44 GHz 5087-7184
6 A19 SBTX/RYTHM Assembly, 50 GHz 5087-7185
7 A20 Low Band Assembly E4440-60217
8 FL1 Low Pass Filter, 3 GHz 0955-0988
9 A21 FELOMA (Frequency Extended LO
Multiplying Amplifier)
5087-7126
10 FL2 Band Pass Filter, 3.9214 GHz 0955-1074
11 A29 SBTX Driver Board E4446-60005
12 A30 FIFA, First IF Amplifier Assembly E4446-60007
13 Bracket, FIFA/cable restraint for Lowband
assembly (E4447A only)
E4447-60001
