Chapter 10 281
Replaceable Parts Lists and Locations
Hardware
Reference
Designator
Description Agilent Part
Number
1 1st LO OUT connector SMA (Option AYZ) 1250-1666
2 IF INPUT connector SMA (Option AYZ) 1250-1666
A22 A22 Preamp Assembly (Option 1DS) E4440-60444
A27 A27 Electronic Attenuator (Option B7J) E4440-60456
W45 W45 Cable, semi-rigid, LO OUT from front-panel to W46
(Option AYZ)
E4440-20095
W46 W46 Cable, semi-rigid, LO OUT extension cable from A21
FELOMA LO OUT to W45. (Option AYZ and 123, for PSA >
26.5 GHz)
E4446-20035
W48 W48 Cable, semi-rigid, FL1 Low Pass Filter to A22 Preamp
Assy. (Option 1DS)
E4446-20038
W50 W50 Cable, semi-rigid, Preamp Out from A22 Preamp to
Lowband (Option 1DS)
E4440-20079
W51 W51 Cable, semi-rigid, A19 SBTX/RYTHM out to A27
Electronic Attenuator (Option B7J)
E4446-20039
W52 W52 Cable, semi-rigid, A27 electronic attenuator to FL1, 3 GHz
Low Pass Filter (Option B7J)
E4446-20040
