Chapter 10
297
Replaceable P
ar
ts Lists and Locations
Hard
ware
Figure 10-31
Disk Drive Parts
Item
Descri
ption
Agilent Part
Number
1 and 4
D
i
sk Drive Mount
E4406-40006
2
A23 Floppy Disk Drive
0950-2782
3
Disk Drive Board
E4406-60014
296
298
