2-6 E8356-90001
Installing Your Analyzer
STEP 3. Install the Analyzer on a Bench Top or in an Equipment Rack
STEP 3. Install the Analyzer on a Bench Top or in an
Equipment Rack
IMPORTANT
Please review all safety information located in Chapter 4 , “Safety,
Regulatory, and Environmental Information” before proceeding with
installing and using the analyzer.
The analyzer can be installed on a bench top or in an equipment rack. When installing an
analyzer equipped with handles
1
in an equipment rack, use Option 1CP
2
. When installing
an analyzer not equipped with handles in an equipment rack, use Option 1CM.
In all installations, consider the following ventilation requirements when deciding where
to set up your analyzer.
CAUTION
Ventilation Requirements: When installing the product in a cabinet, the
convection into and out of the product must not be restricted. The ambient
temperature (outside the cabinet) must be less than the maximum operating
temperature of the instrument by 4 ×C for every 100 watts dissipated in the
cabinet. If the total power dissipated in the cabinet is greater than 800 watts,
then forced convection must be used.
Refer to the section, listed below, that applies to your installation.
To Install on a Bench Top
When you install the analyzer for bench top use, you may wish to attach the supplied
handles
1
to the analyzer.
If you wish to install the handles
1
, follow the instructions provided with the handle kit.
To Install in an Equipment Rack
(Option 1CP
2
- Rack Mounting For Instruments Equipped With
Handles
1
)
(Option 1CM - Rack Mounting For Instruments Not Equipped With
Handles)
When you install the analyzer in an equipment rack, you must install rails in the rack to
support the weight of the analyzer. Attach either the Option 1CP
2
or Option 1CM rack
mount flanges to the analyzer. Secure the analyzer to the equipment rack. Replace the
analyzer bottom plastic feet with the hole plugs provided.
For installation, follow the instructions provided with the rack mount kit and the rail kit.
1. Front handles are not available for the N5242A.
2. Option 1CP is not available for the N5242A.
