TriScroll 800 Inverter Vacuum Pump
2
Installation Requirements
Safety
Do not remove or modify any safety or insulating
equipment from the pump. To do so may create a serious
safety hazard and may void the warranty.
During operation, the following environmental
conditions should not be exceeded:
WARNING ❑ This pump is designed to pump
and exhaust air and inert gases only;
it is not designed to pump explosive,
flammable, toxic, or corrosive gases.
They can cause bodily injury,
explosion, or fire.
❑ Install in an area that is not
exposed to rain, steam, or excessive
humidity. They can cause electric
shock, short circuits, and severe
bodily injury.
❑ Before inspecting or servicing the
pump, be sure the electrical supply
is disconnected.
❑ Consult a qualified electrician
whenever wiring the pump.
❑ An exhaust silencer option is
available for those applications in
which it is desirable to diminish the
sound level produced by the pump.
❑ To prevent bodily injury, avoid
exposing any part of the human
body to vacuum.
❑ The pump is a heavy object. To
avoid muscle strain or back injury,
use lifting aides and proper lifting
techniques when removing or
replacing.
CAUTION Although the pump can pump trace
particulates normally found in the
atmosphere, it is not designed for
process solids, chemicals, powders,
solvents, condensates, or other par-
ticulates. They can damage the
equipment, degrade its performance,
or shorten its useful life.
The pump operates in a clockwise
direction when viewed from the
motor end. (Note the arrow on the
pump frame.) Improper rotation can
cause permanent damage to the
pump.
Temperature: +5 °C to +40 °C (41 °F to 104 °F)
Relative humidity: 0 to 95% (non-condensing)
CAUTION Do not block the fan ducts because the
pump can become overheated. A pump
surface temperature in excess of 55 °C
(131 ° F) is potentially damaging. If such
conditions are observed, turn pump off
and allow to cool. Disassemble, inspect
for damage, and repair if necessary.
CAUTION To reduce the risk of electric shock,
do not expose to rain; store indoors.
