TriScroll 800 Inverter Vacuum Pump
6
TriScroll 800 Inverter Pump Components View
Figure 1 TriScroll 800 Inverter Vacuum Pump
2
1
1
3
4
5
7
8
16
15
14
13
12
11
10
6
9
Cowling Screws; M5 (3) (two shown)
Cowling
Inlet (NW40)
Inlet Screen
Bearing Purge Port (1/4” NPT)
Gas Ballast Port (1/4” NPT)
Mounting Holes; 11 mm diameter thru (8)
Rubber Feet (4)
Integrated VPI Valve
VPI Solenoid
VPI Communication Cable
Power Connector (IEC 320)
On/Off Switch
Serial Port J1
Interlock Port P1 I/O-1
Interlock Port P2 I/O-2
NW25 Exhaust Adapter (Not Shown)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
