TriScroll 800 Inverter Vacuum Pump
DRA
FT 10/9/14
Power Cord
Several power cord options are available from your
Agilent dealer. Descriptions of the available power cords
and their ordering numbers are given in Table 1.
Grounding Instructions
This product should be grounded. In the event of an elec-
trical short circuit, grounding reduces the risk of electric
shock by providing an escape wire for the electric current.
This pump is equipped with a power cord that has a
grounding wire with an appropriate grounding plug. The
plug must be inserted into an outlet that is properly
installed and grounded in accordance with all local codes
and ordinances.
Extension Cords
If you must use an extension cord with this product:
❑ Agilent recommends using only extension cords
with a minimum of 16-gauge wire and a
maximum length of 25’ (7.6 m).
❑ Use only a 3-wire extension cord that accepts the
plug.
❑ Ensure the extension is in good condition.
❑ Ensure the extension cord is rated high enough to
carry the current the products draws. An
undersized cord causes a drop in line voltage,
resulting in loss of power and overheating.
Circuit Breakers
Table 2 lists the circuit breaker capacity required for the
pump. Locate the switch or circuit breaker near the pump.
NOTE The pump must be connected to the
power supply using a high voltage
IEC-320 type power cord of at least 10
A capacity.
Table 1 Power Cord Selection
Country Power Cord Specification Order
Europe 10 A / 220-230 VAC, 2.5 m 656494220
Denmark 10 A / 220-230 VAC, 2.5 m 656494225
Switzerland 10 A / 230 VAC, 2.5 m 656494235
UK/Ireland 13 A / 230 VAC, 2.5 m 656494250
India 10 A / 220-250 VAC, 2.5 m 656494245
Israel 10 A / 230 VAC, 2.5 m 656494230
North
America
10 A / 230 VAC, 2.5 m 656494255
WARNING Check with a qualified electrician or
serviceman if the grounding instructions
are not completely understood, or if
you are in doubt as to whether the
product is properly grounded.
Do not modify the plug provided; if it
does not fit the outlet, have the proper
outlet installed by a qualified electrician.
Connect the product only to an outlet
that has the same configuration as the
plug.
Do not use an adapter with this
product.
WARNING ❑ Protect against short circuits by
installing a circuit breaker of the
proper capacity.
❑ The circuit breaker must be suit-
ably located and easily reached.
❑ The circuit breaker must be
marked at the disconnecting device
for the equipment with the on/off
symbol I/O and meet the relevant
requirements of IEC60947-1 and
IEC60947-3.
Table 2 Circuit Breaker Requirements
PTS08001INV 200-240 VAC
50/60 Hz
Breaker capacity 10 Amperes
