7
TriScroll 800 Inverter Vacuum Pump
DRAFT 10/9/14
Technical Information
Table 3 Specifications
Model TriScroll™ 800 Inverter Dry Scroll Vacuum Pump (PTS08001INV)
Interface dimensions See Figure 2
Peak pumping speed 800 l/m, 48m
3
/hr (28.3 cfm)
See Figure 3
Media Clean air. No toxic, corrosive, explosive or particulate forming gases
Ultimate pressure (Torr) 10.0 x 10
-3
Torr (13.3 x 10
-3
mbar)
Maximum inlet pressure 1.0 atmosphere (0 psig)
Maximum continuous inlet pressure 100 Torr
Maximum outlet pressure 1.1 atmosphere (1.5 psig)
Inlet connection NW40
Exhaust connection Female 3/8" National Pipe Thread (NW25 adapter provided)
Gas ballast Female 1/4" National Pipe Thread (40 Micron sintered filter provided)
Ambient operating temperature 5 °C to 40 °C (41 °F to 104 °F)
Storage temperature –20 °C to 60 °C (–4 °F to 140 °F)
Motor rating 1.0 HP (0.75 kW)
Operating voltage 50-60 Hz:200-240 VAC Single-phase ±10%, 1200 VA
Maximum line current 200 VAC; 6 A
240 VAC; 5A
Motor Thermal Protection Automatic
Operating speed 35-65 Hz Factory setting: 62 Hz, 1800 RPM
Cooling system Air-cooled
Weight Pump only: 32 kg (71 lbs)
Shipping weight: 42 kg (92 lbs)
Noise level (per ISO 11201) Variable with frequency, 58-71 dB(A)
Vibration level at inlet (per ISO 10816-1) Variable with frequency
Main fuse 12.5 A, 250 V
Installation and storage Installation category 2, indoor usage and storage
Pollution degree 2
Altitude 2000 m
