6 Specifications and Characteristics
90 U3402A User’s and Service Guide
General Characteristics
POWER SUPPLY
• 100 V/120 V/220 V/240 V ± 10%,
• AC line frequency 50 Hz to 60Hz
POWER CONSUMPTION
16 VA maximum
INPUT POWER OPTION
Manual ranging (100 VAC to 240 VAC ±10%)
FUSE
Te r m i n a l :
• 1.25 A, 500 V FB fuse
• 15 A, 600 V FB fuse (internal)
Power line (according to country of destination):
• 0.25 A, 250 V SB fuse, or
• 0125 A, 250 V SB fuse
DISPLAY
Highly visible vacuum fluorescent display (VFD)
OPERATING ENVIRONMENT
• Operating temperature from 0 °C to +50 °C
• Relative humidity up to 80% at 28 °C RH (non-condensing)
• Altitude up to 2000 meters
• Pollution degree 2
• For indoor use only
STORAGE COMPLIANCE
• –20 °C to 60 °C
• Relative humidity at 5% to 90% RH (non-condensing)
U3402-90001.book Page 90 Friday, July 24, 2009 4:04 PM
