Replaceable Parts
This section contains information for ordering replacement parts for your
instrument. The parts lists are divided into the following sections.
Parts are listed in alphanumeric order according to their reference
designators. The parts lists include a brief description of each part with
applicable Agilent part number.
To Order Replaceable Parts
You can order replaceable parts from Agilent using the Agilent part number.
Note that not all parts listed in this chapter are available as field–replaceable
parts. To order replaceable parts from Agilent, do the following:
1 Contact your nearest Agilent Sales Office or Service Center.
2 Identify the parts by the Agilent part number shown in the replaceable
parts list.
3 Provide the instrument model number and serial number.
Ta b l e 5- 2 Replaceable Parts
Part Number Description
A02-16-25077-6 Keypad
U3402-60202 Front panel assembly
A02-15-25453-1 Pushrod
A02-1-25370-1C Cover
A02-15-25200-1 Rear bezel
U3401-40001 Rubber bumper kit (front and rear)
U3606-45001 Carrying handle
2110-1394 1.25 A, 500 V fuse (mA input)
2110-1396 15 A, 600 V Fast acting fuse (A input)
A02-62-25592-3U 0.25 A, 250 V time-lag, low-breaking, line power fuse
A02-62-25648-1U 0.125 A, 250 V time-lag, low-breaking, line power fuse
A02-62-25604-1
Front panel fuse holder
34405-40001 Fuse holder assembly on rear panel
