Measurement Specification
AC voltage
Measurement method
AC coupled true RMS—measure the AC
component with up to 400 VDC bias on any range
Crest factor Maximum 3:0 at full scale
Input impedance 1 M
W ± 2% in parallel with <120 pF on all ranges
Maximum input voltage
750 V RMS /1100 V PEAK
2x10
7
V-Hz product on any range, normal mode
input
1x10
6
V-Hz product on any range, common mode
input
Overload ranging
Will select higher range if peak input overload is
detected during autorange. Overload is reported
in manual ranging.
Input protection 750 V RMS on all ranges
Response time
Approximately 1.5 seconds when the displayed
reading reaches 99.9% AC RMS value of the
tested input signal at the same range.
AC voltage (true
RMS, AC+DC
coupling mode)
Measurement method
AC+DC coupled true RMS—measure the AC
component with up to 400 VDC bias on any range
Crest factor Maximum 3:0 at full scale
Input impedance 1 M
W ± 2% in parallel with <120 pF of all ranges
Maximum input voltage
750 V RMS /1100 V PEAK
2x10
7
V-Hz product on any range, normal mode
input
1x10
6
V-Hz product on any range, common mode
input
Overload ranging
Will select higher range if peak input overload is
detected during autorange. Overload is reported
in manual ranging.
Input protection 750 V RMS on all ranges
Response time
Approximately 2.5 seconds when the displayed
reading reaches 99.9% AC RMS value of the
tested input signal at the same range.
Table 6-13 Supplemental measurement specifications
