U3402A User’s and Service Guide xix
List of Tables
Ta b l e 1 - 1 Display annunciators 10
Ta b l e 1 - 2 Keypad functions 12
Ta b l e 1 - 3 Input terminal for different measurement functions 16
Ta b l e 2 - 1 Range scale value in slow, medium, and fast reading rate 33
Ta b l e 2 - 2 Reading rates for single function measurements 34
Ta b l e 2 - 3 Description for dual display combination 37
Ta b l e 2 - 4 Setup menu and communication parameters 38
Ta b l e 2 - 5 Math operations for different measurement functions 41
Ta b l e 2 - 6 Descriptions for combined math operations 49
Ta b l e 3 - 1 Typical combinations and applications when using dual display 52
Ta b l e 4 - 1 Recommended test equipments 63
Ta b l e 4 - 2 DC voltage verification test 66
Ta b l e 4 - 3 DC current verification test 67
Ta b l e 4 - 4 2-wire
W
verification test 68
Ta b l e 4 - 5 4-wire
W
verification test 69
Ta b l e 4 - 6 Diode verification test 71
Ta b l e 4 - 7 Frequency verification test 71
Ta b l e 4 - 8 AC volts verification test 72
Ta b l e 4 - 9 AC current verification test 73
Ta b l e 5 - 1 Type of supplied fuse (according to country of destination) 79
Ta b l e 5 - 2 Replaceable Parts 87
Ta b l e 6 - 1 DCV resolution, full scale reading, and accuracy [±(% of reading +
count)] 93
Ta b l e 6 - 2 DCI resolution, full scale reading, and accuracy [±(% of reading +
count)] 94
Ta b l e 6 - 3 ACV resolution, full scale reading, and accuracy [±(% of reading +
count)] 95
Ta b l e 6 - 4 ACVac+dc resolution, full scale reading, and accuracy [± (% of reading +
count)] 96
Ta b l e 6 - 5 ACI resolution, full scale reading, burden voltage, and accuracy [± (% of
reading + count)] 97
Ta b l e 6 - 6 ACIac+dc resolution, full scale reading, burden voltage, and accuracy [± (%
of reading + count)] 98
