Agilent Technologies U8001A - Rear Panel at a Glance

General Information 2
U8001A/U8002A User’s and Service Guide 9
Rear Panel at a Glance
1
2
3
4
5
Panels Functions
1 AC inlet Connects AC power line.
2 Power fuse-holder
assembly
Sets the line voltage to the proper values for different country based.
3 Power-line module Combination of the AC inlet and power fuse-holder assembly.
4 Physical lock mechanism Enables physical lock mechanism.
5 Line Voltage Fuse Rating
indicator
Indicates the line voltage and line fuse rating.
