32 U8001A/U8002A User’s and Service Guide
4 Specifications and Characteristics
Performance Specifications
Table 4 - 1 Electrical Specifications
Parameter U8001A U8002A
Output Ratings (at 0 °C to 40 °C) 0 to +30 V
0 to 3 A
0 to +30 V
0 to 5 A
Line and Load Regulation CV: <0.01% +2 mV
CC: <0.02% +2 mA
Ripple and Noise (25 °C ±5 °C) CV: 12 mVp-p, <1 mVrms;
CC: 3 mArms
Load Transient Response Time
(within 15 mV from full load to half load
and from half load to full load)
<50 µs
Programming Accuracy
*
(25 °C ±5 °C) <0.35% +20 mV
<0.35% +20 mA
Readback Accuracy
*
(25 °C ±5 ° C) <0.35% +20 mV
<0.35% +20 mA
Meter Resolution Voltage: 10 mV
Current: 10 mA
Maximum Output Float Voltage ±240 Vdc
* Specifications are based on 1-hour warm-up period.
