38 U8001A/U8002A User’s and Service Guide
5Service Guide
Replacement Parts
This section contains information for ordering replacement
parts for your instrument. The parts lists are divided into the
following sections.
• Parts are listed in alphanumeric order according to their
reference designators
• The parts lists include a brief description of each part with
applicable Agilent part number.
To Order Replaceable Parts
You can order replaceable parts from Agilent using the Agilent
part number. Note that not all parts listed in this chapter are
available as field–replaceable parts. To order replaceable parts
from Agilent, do the following:
1 Contact your nearest Agilent Sales Office or Service Center.
2 Identify the parts by the Agilent part number shown in the
replaceable parts list.
3 Provide the instrument model number and serial number.
Table 5 - 1 Replaceable Parts
Part Number Description
U8001-60002 Front Panel Assembly (U8001)
U8002-60002 Front Panel Assembly (U8002)
U8001-66502 Main PCA (U8001A)
U8002-66502 Main PCA (U8002A)
U8001-60007 Transformer (90 W)
U8002-60007 Transformer (150 W)
2110-0014 Fuse 4.0 A T for 100 Vac and 115 Vac (U8001A)
2110-0006 Fuse 2.0 A T for 230 Vac (U8001A)
2110-0722 Fuse 6.25 A T for 100 Vac and 115 Vac (U8002A)
2110-1425 Fuse 2.8 A T for 230 Vac (U8002A)
