Operations and Features 3
U8001A/U8002A User’s and Service Guide 21
5 Adjust for the desired output current.
• Press on the “Voltage/Current” button. When seeing the
current value, “A” blinks, turn the knob to adjust for the
desired output current value.
6 Return to the meter mode.
• Press on the “Display Limit” button to return to the meter
mode. The LIMIT annunciator will be turned off.
7 Enable the output.
• Press on the “Output On/Off” button to enable the output.
• The OFF annunciator turns off and constant current (CC)
annunciator turns on.
• The display is now in meter mode.
Verify that the power supply is in constant current mode. Ensure that the
constant current (CC) annunciator is on. If the constant voltage (CV)
annunciator is on instead, choose a higher voltage limit.
