Service Guide 5
U8001A/U8002A User’s and Service Guide 41
Orientation of the Voltage Selector AC Inlet
Figure 5-1 Orientation of voltage selector AC inlet in different voltage
selection
100 indication needs to be in this orientation
115 indication needs to be in this orientation
230 indication needs to be in this orientation
115 V
230 V
100 V
